With its advanced illumination and megapixel camera, NVH300 Angler HD provides superior performance. It is ideal for scanning high-density 1D/2D or DPM barcodes, even on reflective, curved, and shiny surfaces.
High-Performance HD Decoding
The NVH300 Angler HD is equipped with direct white and red diffuse illumination to ensure barcodes can be scanned from different materials, shapes, colors, and complex backgrounds. With an IP42 housing and a 1.8 drop rating, the NVH300 Angler HD is designed to operate in harsh environments.
- General Information
- Manufacturer
- Newland
- Manufacturer Website Address
- http://www.newlandna.com/
- Brand Name
- Newland
- Product Type
- Barcode Scanner
- Warranty
- Limited Warranty
- 5 Year
- Technical Information
- Connectivity Technology
- Cable
- Scanning Capability
- 1D
- 2D
- Barcode Symbology Supported
- 1D:
- EAN 8
- EAN 13
- UPC E
- UPC A
- Code128
- Coupon
- UCC/EAN128
- CodaBar
- I2Of5
- Febraban
- ITF14
- ITF6
- Matrix 25
- Code39
- Code93
- ISSN
- ISBN
- Industrial 25
- Standard 25
- China Post 25
- Plessey
- Code 11
- MSI Plessey
- UCC/EAN Composite
- GS1 Databar
- Code 49
- Code 16K
- AIM 128
- ISBT 128
- PDF417
- Micro PDF417
- QR Code
- Micro QR Code
- Aztec
- Data Matrix
- Chinese Sensible Code
- Maxicode
- Light Source
- Laser
- Image Sensor Type
- CMOS
- Depth of Field
- Depth of Field Code 39 (5mil) 18mm-90mm
- Depth of Field DataMatrix (10mil) 0mm-90mm
- Depth of Field QR (10mil) 0mm-90mm
- Scanner Range
- High Density
- Scanning Distance
- 3.54"
- Cable Type Included
- USB
- Field of View (Horizontal)
- 41°
- Field of View (Vertical)
- 31°
- Reading Angle (Skew)
- 55°
- Reading Angle (Roll)
- 360°
- Motion Tolerance
- 78.74 in/s
- Drop Specification
- 1.8m
- Minimum Print Contrast
- 20%
- Minimum Element Resolution (Code 39)
- 5 mil
- Minimum Element Resolution (DataMatrix)
- 10 mil
- Direct Part Marking (DPM) Decoding
- Yes
- Image Sensor Resolution
- 1280 x 960
- Illumination Type
- LED
- Illumination Color
- White
- Air Electrostatic Discharge (+/-)
- 16kV
- Contact Electrostatic Discharge (+/-)
- 8kV
- Interfaces/Ports
- Host Interface
- USB
- Serial
- Power Description
- Maximum Operating Power Consumption
- 2.25 W
- Input Current
- 475 mA
- Environmental Conditions
- Operating Temperature
- -4°F (-20°C) to 122°F (50°C)
- Storage Temperature
- -40°F (-40°C) to 158°F (70°C)
- Humidity (Non-condensing)
- 5% to 95%
- Physical Characteristics
- Form Factor
- Handheld
- Rugged
- Yes
- Height
- 7.3"
- Width
- 3"
- Depth
- 4.2"
- Weight (Approximate)
- 8.29 oz
- Miscellaneous
- Package Contents
- NVH300 Angler HD
- 2 Mtr. USB cable
- Ingress Protection (IP) Rating
- IP42
- Application/Usage
- Industrial
- Manufacturing
- Healthcare
- Software Supported
Software configuraion : Nset
- Environmentally Friendly
- Yes
