• General Information
• • Manufacturer
  • Hanwha Group
  • Manufacturer Website Address
  • http://www.hanwha.com
  • Brand Name
  • Hanwha Techwin
  • Product Series
  • L
  • Product Type
  • Network Camera

• Max. 2megapixel(1920 x 1080) resolution
• H.264, MJPEG codec
• Max. 30fps@2MP (H.264)
• True WDR(120dB), WiseStream?
• Hallway view, LDC(Lens Distortion Correction)
• Motion detection, Tampering
• SD/SDHC memory slot(Max. 32GB), PoE
• IP66 / IK10 support(Vandal-Resistant cameras)

Broad lineup for indoors and outdoors

The newly launched L series cameras consist of very affordable cameras with essential features. The broad line-up includes fixed and varifocal lens depending on its lens type, and bullet, dome and vandal-resistant dome cameras. The cameras have a modern design and can be used both indoors and outdoors.

True WDR(120dB)

The true WDR function built-in into the L series cameras can generate natural images without any image loss even in the challenging environments, such as when the background is brighter than the main object, when an image is obscured by shade due to strong light, when there is a large gap in screen brightness. In addtion, it can significantly reduce the effect of motion blur, which is a critical weakness of conventional WDR.

Improve bandwidth using WiseStream?

WiseStream? is an advanced video compression technology based on motion analytics to maintain video quality whilst reducing the amount of data required. WiseStream? reduces noise and minimizes image quality degradation, which are common problems of traditional image compression artifacts and image noise in low light settings.

Hallway view

In a vertical shaped environment, such as corridors, hallways, tunnels, or aisles, traditional horizontal shaped videos focus on unnecessary edges of the area causing bandwidth and storage waste. By using the hallway view, 3:4 and 9:16 aspect ratio image is created : a verticallly oriented video that maximizes image quality in narrow locations.
