- General Information
- Manufacturer
- Hanwha Group
- Manufacturer Website Address
- http://www.hanwha.com
- Brand Name
- Wisenet
- Product Line
- extraLUX
- Product Series
- X
- Product Type
- Network Camera
- Warranty
- Limited Warranty
- 3 Year
- Technical Information
- Recording Formats
- Full HD
- HD Recording
- Yes
- Display & Graphics
- Image Sensor Type
- CMOS
- Color Supported
- Color
- Field of View
- H: 100.0°(Wide)~26.2°(Tele) / V: 54°(Wide)~14.8°(Tele) / D: 116.0°(Wide)~30.0°(Tele)
- Effective Camera Resolution
- 2 Megapixel
- Video
- Video Formats
- H.265
- H.264 (MPEG-4 Part 10/AVC)
- MJPEG
- H.264
- Maximum Video Resolution
- 1920 x 1080
- Maximum Frame Rate
- 60 fps
- Analog Video Signal Format
- CVBS
- Lens
- Lens Type
- Varifocal
- Minimum Focal Length
- 4.10 mm
- Maximum Focal Length
- 16.40 mm
- Lens Included
- Yes
- Lens Mount Type
- Board Mount
- Minimum Aperture
- f/0.94
- Maximum Aperture
- f/2.4
- Optical Zoom
- 4x
- Exposure
- Shortest Shutter Speed
- 1/12000 Second
- Longest Shutter Speed
- 2 Second
- Network & Communication
- Connectivity Technology
- Wired
- Remote Management
- Yes
- Storage
- Storage Type
- Memory Card
- Interfaces/Ports
- Network (RJ-45)
- Yes
- Power Description
- Input Voltage
- 12 V DC
- 24 V AC
- Physical Characteristics
- Mount Type
- Pipe Mount
- Ceiling Mount
- Pole Mount
- Wall Mount
- Box Mount
- Form Factor
- Dome
- Durability
- Vandal Resistant
- Color Family
- White
- Product Color
- Ivory
- Height
- 5.5"
- Diameter
- 6.3"
- Weight (Approximate)
- 3.09 lb
- Environmental Conditions
- Minimum Operating Temperature
- -40°F (-40°C)
- Maximum Operating Temperature
- 131°F (55°C)
- Maximum Operating Humidity
- 90%
- Miscellaneous
- Features
- Wide Dynamic Range
- Motion Detection
- Tamper Detection
- SD Card Local Storage
- Day/Night
- 2D Digital Noise Reduction (2DNR)
- 3D Digital Noise Reduction
- Privacy Masking
- Gain Control
- Automatic White Balance
- Back Light Compensation (BLC)
- Highlight Compensation (HLC)
- Defog
- Indoor/Outdoor
- Outdoor
- Impact Protection Rating
- IK10
- Ingress Protection Rating
- IP66
- IP67
- NDAA Compliant
- Yes
