- General Information
- Manufacturer
- Bixolon America, Inc
- Manufacturer Website Address
- http://www.bixolon.com
- Brand Name
- Bixolon
- Product Type
- Direct Thermal Printer
Productivity Enhancing Performance
- Fully compatible with market-leading programming languages
- Extensive memory up to 256 MB SDRAM, 512 MB Flash
- Fast data processing and printing speed up to 4 ips (102 mm/sec)
- Supports gap, Black Mark, paper cover open sensor (Fixed Transmissive Sensors)
Reliable Printing on the Move
- Connectivity options including Bluetooth® and Dual-band Wireless Lan (2.4GHz and 5GHz), USB and Serial
- Compatible with all major operating systems including Android™, iOS™ and Windows®
- Supports Easy Bluetooth Pairing™ via embedded NFC tag enabling auto pairing
- Smart Wi-Fi setting via mobile devices
Rugged and Easy to Carry
- Smallest in its class (143x138x66 mm)
- Ergonomic and lightweight (530 g)
- 1.8 m / 6 ft. drop rate -
Resistance to water and dust (IP54)
- Various accessories and connectivity ports
- Technical Information
- Recommended Use
- Label Print
- Print Color Capability
- Monochrome
- Maximum Mono Print Speed
- 4.02 in/s
- Maximum Print Resolution (dpi)
- 203
- Maximum Print Width
- 4.09"
- Barcode Symbology Supported
- TLC 39
- QR Code
- Codabar
- Maxi Code
- UPC-E
- UPC-A
- AZTEC
- POSTNET
- Code 11
- Code 93
- Code 39
- Industrial 2 of 5
- IMB
- UPC/EAN
- GS1 DataBar (RSS-14)
- LOGMARS
- MSI
- Plessey
- Interleaved 2 of 5
- Code 128
- EAN-13
- EAN-8
- Standard 2 of 5
- Micro PDF-417
- Application/Usage
- Mobile
- Ticketing
- Healthcare
- Retail
- Logistic
- Features
- Compact
- Rugged
- Ergonomic
- Lightweight
- Water Resistant
- Dust Resistant
- Belt Clip
- Ingress Protection (IP) Rating
- IP54
- Connectivity Technology
- Wireless
- Fonts Included
- Fonts (10 SLCS, 16 BPL-Z, 7 BPL-C)
- Scalable Fonts (1 SLCS, 1 BPL-Z)
- 23 Code page
- Unicode supported (UTF-8, UTF-16LE, UTF-16BE)
- Print Technology
- Direct Thermal
- Memory
- Standard Memory
- 128 MB
- Flash Memory
- 256 MB
- Interfaces/Ports
- Serial Port
- Yes
- USB Host
- Yes
- USB
- Yes
- USB Standard
- USB 2.0
- Network & Communication
- Bluetooth
- Yes
- Wireless LAN
- Yes
- Wireless LAN Standard
- IEEE 802.11a/b/g/n
- Near Field Communication (NFC)
- Yes
- Display & Graphics
- Display Screen
- Yes
- Screen Size
- 4"
- Display Screen Type
- LCD
- Media Types & Handling
- Media Type
- Label
- Linered Label
- Media Sensor
- Paper End Sensor
- Gap Sensor
- Black Mark Sensor
- Cover Open Sensor
- Media Thickness
- 7.48 mil
- Maximum Roll Diameter
- 2.20"
- Maximum Label Width
- 4.41"
- Fonts & Emulation
- Language Emulation
- SLCS
- BPL-Z
- BPL-C
- ZPL II
- CPCL
- Software
- Operating System Supported
- Windows
- iOS
- Linux
- Android
- Power Description
- Power Source
- Battery
- Battery Information
- Battery Chemistry
- Lithium Ion (Li-Ion)
- Battery Included
- Yes
- Battery Capacity
- 2850 mAh
- Environmental Conditions
- Operating Temperature
- 5°F (-15°C) - 122°F (50°C)
- Operating Relative Humidity
- 10% - 80%
- Storage Temperature
- -22°F (-30°C) - 158°F (70°C)
- Physical Characteristics
- Height
- 2.6"
- Width
- 5.6"
- Depth
- 5.4"
- Weight (Approximate)
- 1.17 lb
- Miscellaneous
- Package Contents
- SPP-L410 4 inch Mobile Label Printer
- Belt Clip
- Battery
- Battery Charger
- Power Cord
- Compatibility
- iPod
- iPad
- iPhone
- Platform Supported
- PC
- Energy Star
- Yes
