- General Information
- Manufacturer
- ANKER
- Manufacturer Website Address
- http://us.anker.com
- Brand Name
- ANKER
- Product Type
- Docking Station
Unlock Triple Display for M1 MacBooks
Get More From Your MacBook
A total of 10 ports let you access triple-monitor display, high-speed file transfer, powerful charging, USB connectivity, Ethernet, and audio connectivity-all from just one dock.
Media Display Information
When connected to a single monitor: 4K@30Hz via the 1st HDMI port, 2K@50Hz via the 2nd HDMI port, 2K@60Hz via the DisplayPort.
When connected to two monitors: 4K@30Hz + 2K@50Hz (via both HDMI ports); 4K@30Hz + 2K@60Hz (via the 1st HDMI port and the DisplayPort); 2048×1152@60Hz + 2048×1152@60Hz (via the 2nd HDMI port and the DisplayPort.
When connected to three monitors: 4K@30Hz (HDMI) + 2048×1152@60Hz (HDMI) + 2048×1152@60Hz (DisplayPort).
- Warranty
- Limited Warranty
- 18 Month
- Technical Information
- Connectivity Technology
- Wired
- Charging Capability
- Yes
- Device Supported
- Headphone
- Flash Drive
- Keyboard
- Monitor
- Mouse
- Notebook
- Smartphone
- Features
- Power Delivery Pass-through
- Number of Displays Supported
- 3
- Screen Mode Supported
- 4K UHD
- 4K
- 2K
- Full HD
- Supported Resolutions
- 3840 x 2160
- 2560 x 1440
- 2048 x 1152
- 1920 x 1080
- Maximum Data Transfer Rate
- 640 MB/s
- Network & Communication
- Ethernet Technology
- Ethernet
- Interfaces/Ports
- Host Interface
- USB Type C
- Total Number of USB Ports
- 4
- Number of USB 2.0 Ports
- 2
- Number of USB 3.1 Gen 1 Type-A Ports
- 1
- Number of USB Type-A Ports
- 3
- Number of USB Type-C Ports
- 1
- USB Type-A
- Yes
- USB Type-C
- Yes
- USB Type-C Detail
- USB-C 3.2 Gen 1 port
- Network (RJ-45)
- Yes
- Number of RJ-45 Ports
- 1
- Number of DisplayPorts
- 1
- DisplayPort
- Yes
- Headphone/Microphone Combo Port
- Yes
- Number of HDMI Ports
- 2
- HDMI
- Yes
- USB Power Delivery
- 100W
- Software
- Operating System Supported
- Mac OS X 10.14 Mojave
- Windows 7
- Windows 10
- Windows 11
- Windows 8
- Power Description
- Maximum Power Supply Wattage
- 180 W
- Power Source Type
- Power Adapter
- Physical Characteristics
- Color Family
- Gray
- Product Color
- Gray
- Miscellaneous
- Package Contents
- 563 USB-C Docking Station
- 180W Power Adapter
- USB-C 3.1 Gen 2 Cable
- Welcome Guide
- Compatibility
Apple Products:
- M1 MacBooks
- iPhone 13 Pro
- MacBook Air
- Brand Compatibility
- Apple
